SOCKET SIZE CHART FOR METRIC AND STANDARD

Socket size chart for metric and standard

Socket size chart for metric and standard

Sockets come in many sizes and can get confusing with what is bigger than the other. In this post, you will find a socket size chart for both metric and standard (SAE), in their respective order of size. The three most common drive size types are 1/4″, 3/8″, and 1/2″. You can learn more about drive types here. Each drive type will carry from and up to a certain size socket until another drive type is needed.

Socket Size Chart For Metric

1/4″ Drive3/8″ Drive1/2″ Drive3/4″ Drive1″ Drive
4mm5.5mm8mm19mm36mm
4.5mm6mm9mm20mm38mm
5mm7mm10mm21mm41mm
5.5mm8mm11mm22mm46mm
6mm9mm12mm23mm50mm
7mm10mm13mm24mm54mm
8mm11mm14mm25mm55mm
9mm12mm15mm26mm58mm
10mm13mm16mm27mm60mm
11mm14mm17mm28mm63mm
12mm15mm18mm29mm65mm
13mm16mm19mm30mm67mm
14mm17mm20mm31mm70mm
15mm18mm21mm32mm71mm
 19mm22mm33mm75mm
 20mm23mm34mm77mm
 21mm24mm35mm80mm
 22mm25mm36mm
  26mm38mm
  27mm40mm
  28mm41mm
  30mm42mm
Metric socket sizes in order

Socket Size Chart For Standard

1/4″ Drive3/8″ Drive1/2″ Drive3/4″ Drive1″ Drive
5/32″1/4″3/8″7/8″1-5/8″
3/16″5/16″7/16″15/16″1-11/16″
7/32″3/8″1/2″1″1-3/4″
1/4″7/16″9/16″1-1/16″1-13/16″
9/32″1/2″19/32″1-1/8″1-7/8″
5/16″9/16″5/8″1-3/16″2″
11/32″5/8″21/32″1-1/4″2-1/8″
3/8″11/16″11/16″1-5/16″2-3/16″
7/16″3/4″3/4″1-3/8″2-1/4″
1/2″13/16″25/32″1-7/16″2-3/8″
9/16″7/8″13/16″1-1/2″2-1/2″
 15/16″7/8″1-5/8″2-5/8″
 1″15/16″1-11/16″2-3/4″
  1″1-3/4″2-15/16″
  1-1/16″1-13/16″3″
  1-1/8″1-7/8″3-1/8″
  1-3/16″2″
  1-1/4″2-1/8″
  1-1/2″2-3/16″
   2-1/4″
SAE socket sizes in order
